Your Professional Light Steel Keel Roll Forming Machine Supplier
Dongguang Baoqiang Machinery Equipment Co., Ltd. was established in 2017，and is an earlier entity company engaged in Hebei Province to engage in the tile pressing machinery industry.We strictly control every aspect from design to after-sales service, so that our products can help customers improve efficiency, reduce costs, and enhance competitiveness.Our corporate vision is to create an advanced brand in the cold bending industry! Our mission is to enable every customer to use devices that are easy to handle!
Production Equipment
Our company is equipped with advanced large-scale CNC gantry milling machines, CNC floor-type boring and milling machines, high-precision CNC lathes, and machining centers (CNC). From the integral precision machining of machine frames to the efficient cutting of complex rollers and shafts, we comprehensively ensure the accuracy and strength of all core equipment components.
Production Market
Our professional cold roll forming equipment has been exported to more than 60 countries and regions worldwide, establishing an excellent reputation in key markets across all five continents.
After-sales
We provide professional on-site installation, commissioning, and personnel training, and commit to lifetime free remote technical guidance and continuous supply of original spare parts.
Professional Solution
With rich experience and one-to-one service, we can help you choose products and answer technical questions.
High Production Efficiency
One of the main advantages of using a light steel keel roll forming machine is its ability to produce large quantities of keels in a short time. These machines operate at high speeds and automate multiple steps such as cutting, punching, and forming.
Consistent Quality and Precision
Roll forming technology ensures that each steel keel is produced with uniform dimensions and precise specifications. Unlike manual methods, which may result in variations, a roll forming machine guarantees consistency across all products.
Cost-Effective Manufacturing
Using a roll forming machine reduces material wastage and operational costs. The automated process optimizes raw material usage, minimizing scrap and improving efficiency.
Versatility and Customization
Light steel keel roll forming machines can be customized to produce different keel sizes and designs, meeting specific project requirements.
Durability and Low Maintenance
These machines are built with high-quality materials and robust components, ensuring long-term durability. With minimal maintenance, they can operate efficiently for years, reducing downtime and maintenance costs.
Product Paramenters
|
Item |
Common Reference |
|
Suitable material |
Galvanized strip or light steel strip |
|
Thickness range |
Commonly 0.4-1.2 mm |
|
Forming speed |
Around 10-18 m/min, depending on punching |
|
Roller stations |
12-20 stations for common keel profiles |
|
Total power |
About 5.5-11 kW by configuration |
|
Length control |
PLC length setting with encoder feedback |
Key Components of Light Steel Keel Roll Forming Machine
Wall Studs:
Vertical load-bearing members typically featuring pre-punched service holes for electrical and plumbing installations
01
Track Channels:
Horizontal members that form the top and bottom plates of wall systems, providing lateral stability and load distribution
02
Ceiling Grid Systems:
Main tees and cross tees that create suspended ceiling frameworks with precise modular dimensions
03
Furring Channels:
Secondary framing members that create air spaces and provide attachment surfaces for finishing materials
04
Angle Beads and Corner Beads:
Protective and reinforcement components that ensure clean, durable corners and edges
05
Working principle of Light Steel Keel Roll Forming Machine
Roll Forming Stations (Core Process): The flat strip passes through 10 to 18 sets of rollers. Each station applies progressive deformation, gradually bending the steel into the desired cross-sectional shape, such as C-studs, U-tracks, or omega channels. These rollers are typically driven by gears or chains, forcing the metal into specific shapes at room temperature.
Decoiling & Guiding:
A steel coil is placed on a decoiler and fed into the machine. Guide devices align the strip precisely, ensuring it enters the rollers straight.
Leveling:
The strip passes through a leveling unit, which applies pressure to flatten the steel and remove any existing curvatures.
Punching (Optional):
Pre-punching stations, often using servo-driven presses, punch holes for screws or service conduits before the bending begins.
Cutting & Finalization:
A hydraulic system, often controlled by a PLC (Programmable Logic Controller) for high accuracy (pm 0.5mm), cuts the continuously formed profile to the desired length.
Application of Light Steel Keel Roll Forming Machine
Lightweight Steel Framing Systems for Residential and Commercial Buildings
Lightweight steel framing leads the list. Light gauge steel keel roll forming machines make studs, tracks, and joists. These take the place of old wood or heavy steel. In home building, the shapes build the bones for low homes and nice villas.
Interior Partition Walls and Suspended Ceilings
No new inside space skips bendy walls. Light steel keel roll forming machines shine here. They shape non-weight walls with C and U profiles. These match easy with gypsum board or sound panels.
Drywall Systems and Cladding Solutions
Drywall setup needs light steel metal keel roll forming machines a lot. They make furring channels and tough bars. These stop sound from room to room. In group homes, they cut noise by up to 50dB. That gives quiet living.
Roofing, Prefabricated Structures, and Modular Housing
Roof jobs use hat channels and Z-purlins from these machines. They work for steep or flat roofs in storage spots and gyms. Light weight makes moving and putting up easy. It cuts crane time and worker costs.
Industrial and Agricultural Extensions
Uses go past city builds. They reach factories, car sheds, and farm buildings. The machine makes strong trusses for big roof spans in plants. They hold heavy tools without drop.
FAQ
We are one of the most professional light steel keel roll forming machine manufacturers and suppliers in China, featured by quality products and good price. Please feel free to buy durable light steel keel roll forming machine for sale here from our factory. Contact us for more details.
