Your Professional Window Frame Machine Supplier
Dongguang Baoqiang Machinery Equipment Co., Ltd. was established in 2017，and is an earlier entity company engaged in Hebei Province to engage in the tile pressing machinery industry.We strictly control every aspect from design to after-sales service, so that our products can help customers improve efficiency, reduce costs, and enhance competitiveness.Our corporate vision is to create an advanced brand in the cold bending industry! Our mission is to enable every customer to use devices that are easy to handle!
Production Equipment
Our company is equipped with advanced large-scale CNC gantry milling machines, CNC floor-type boring and milling machines, high-precision CNC lathes, and machining centers (CNC). From the integral precision machining of machine frames to the efficient cutting of complex rollers and shafts, we comprehensively ensure the accuracy and strength of all core equipment components.
Production Market
Our professional cold roll forming equipment has been exported to more than 60 countries and regions worldwide, establishing an excellent reputation in key markets across all five continents.
After-sales
We provide professional on-site installation, commissioning, and personnel training, and commit to lifetime free remote technical guidance and continuous supply of original spare parts.
Professional Solution
With rich experience and one-to-one service, we can help you choose products and answer technical questions.
Advantages of Window Frame Machine
Increased Speed and Productivity:
Automated, high-speed production, with some roll-forming units operating at speeds up to 30 meters per minute.
High Precision and Quality:
Advanced cutting, bending, and welding technologies ensure precise, consistent dimensions, reducing human error and improving structural strength.
Enhanced Safety and Reduced Labor:
Automated, advanced, and efficient upvc window frame cutting machines minimize manual intervention, reducing labor requirements and increasing safety by decreasing accident risks in manufacturing environments.
Versatility and Customization:
Machines are designed to handle various profiles, shapes, and sizes, allowing for easy adjustment to produce custom window designs, as shown with Window Frame Making Machines.
Specification
|
Parameter |
Details |
|
Raw Materials |
Galvanized steel, colored steel coils, aluminum sheets |
|
Material Thickness |
0.3-1.2mm (customizable up to 1.5mm) |
|
Production Speed |
0-25m/min (adjustable with frequency control) |
|
Total Power |
7.5kW (5.5kW main motor + 3kW hydraulic motor) |
|
Power Supply |
380V 3-phase 50Hz (customizable) |
|
Machine Dimensions |
5500×800×900mm |
|
Machine Weight |
3300kg |
Types of Window Frame Machine
Corner Crimping/Assembly Machines: Used to join corner profiles securely, often using hydraulic power for strong, durable connections.
Copy Routing Machine:
Designed to rout or mill slots for locks, handles, and hinges on the window frame.
End Milling Machine:
Used for machining the end of aluminium profiles to connect with other profiles.
Multi-spindle Pneumatic Punching Machine:
Used to create holes and shapes in the profiles for hardware installation.
Corner Cleaning Machine:
Primarily used for cleaning excess weld on uPVC windows, but also used to refine corners for a clean finish.
Window Frame Machine Workflow
Uncoiling Machine → Leveling Device → Pit/Ground Stacking Device (Optional) → Servo Feeding Device → Punching Device → Pit/Ground Stacking Device (Optional) → Guiding Device → Roll Forming System → Post-cutting to the required length (optional flying cut, tracking cut, and stop cut) → Output Manual Support/Automatic Stacker (Optional)
Application of Window Frame Machine
Customization:
Specialized tools enable tailoring frames to specific designs and sizes.
01
Material Processing:
Handling materials like galvanized steel, stainless steel, and uPVC for various frame profiles.
02
High-Speed Manufacturing:
Utilizing automated, non-stop feeding and cutting to improve production efficiency by over 40%.
03
Specialized Components:
Producing screen frames (e.g., Brother Union Machinery's steel profiles), fire-rated frames, and structural components.
04
Advanced Fabrication:
Offering CNC-controlled precision for complex tasks like corner cleaning, milling, and drilling for precise assembly.
05
FAQ
We are one of the most professional window frame machine manufacturers and suppliers in China, featured by quality products and good price. Please feel free to buy durable window frame machine for sale here from our factory. Contact us for more details.
